SAAS Mitsubishi Triton 2.5L MN 4x4 Silicone Airbox to Turbo Intake Pipe | SSH3301

SAAS Mitsubishi Triton 2.5L MN 4x4 Silicone Airbox to Turbo Intake Pipe (part number SSH3301) is available from JDM Mods NQ. Review the specifications and fitting notes below to confirm suitability for your setup.

SSH3301 Silicone Airbox to Turbo Intake Pipe Triton 2.5L MN 2009 - 2015 4x4

Suits:

• 2.5L
• MItsubishi Triton MN 4x4 only 2009 - 2015
• Please check your Airbox diameter before ordering
  • Airbox - 70mm
  • Turbo - 46mm
  • Crankcase Return Valve - 22mm

Our 7 Ply Silicone Airbox to Turbo Intake hoses are the ideal replacement/upgrade for factory or OE style rubber hoses and come supplied with our dual bead stainless hose clamps

The SAAS SSH3301 is designed to replace the factory airbox to turbo intake and provides additional protection under high boost with its uprated 7 ply reinforced laminate construction. The 8mm wall thickness ensures maximum strength and distortion free operation. Be aware that the increased rigidity of our multi-ply laminate means you may need to use a silicone lubricant or grease for installation.

The kit also features our new Stainless Dual Bead clamps which provide greater clamping pressure whilst mitigating the risk of cutting into your hose. Don't be caught out with a split rubber hose roadside - upgrade to SAAS Silicone hoses today.

FVMQ Oil Resistance: FVMQ Fluorosilicones offer the highest level of oil resistance amongst the most common elastomers and are a popular solution within the aviation industry

Features

• Smooth Form 7 Ply polyester reinforced silicone
• 8mm wall thickness prevents "hose collapse"
• Red FMVQ Fluorosilicone lining providing greater resistance to oil mist and EGR by-products (see note)
• Stable operating temp from -50°C to +200°C
• 4:1 burst pressures at safe working loads
• Port provided for factory crankcase return
• Stainless Dual Bead Hose Clamps included
