Radium Fuel Rail, Port Injection, VW/AUDI EA888

20-0889 FUEL RAIL, PORT INJECTION, VW AUDI EA888
Manufactured with A 0.7" large internal bore, the Radium Engineering fuel rail can support all necessary engine power requirements.

PORTS AND FITTINGS

The fuel rail end ports are tapped for 8AN ORB.
The fuel rail upper centre port is tapped for 1/8" NPT.
The fuel rail lower centre port is tapped for 6AN ORB, as shown.
Appropriate fittings must be selected based on the specific application. Ample space around the fuel rail port(s) is necessary for larger accessories such as fuel pressure regulators, fuel pressure gauges, and fuel pulse dampers. To verify clearance, the dimensional drawings on the product pages can be used as a reference guide.

INJECTORS

Like the OEM fuel rails, the injector bores are 14mm ID so factory injectors, or any equivalent aftermarket injector, can be used.

FEATURES
-Lightweight aluminum construction
-Inner bore diameter: 0.7 inch
-Anodized surface finish for wear and corrosion resistance
-Can be converted to a pressure regulated return system
-No special tools required for installation
-Fits under the factory engine cover

20-0889 Includes:
1x EA888 Port Injection Fuel Rail
2x Stainless Screws, M6x1mm
