Link Throttle Position Sensor (TPSCW/CCW)

Link Throttle Position Sensor (TPSCW/CCW)

Available from JDM Mods NQ, the Link Throttle Position Sensor (TPSCW/CCW) is a measurement component for a compatible engine-management installation. Use the fitment, technical and package details below to select the correct part for your build.

Manufacturer part number: 101-0100

Models Supported

• All Link ECUs.
• Other aftermarket ECUs with analogue throttle position inputs.
• 8mm D-shaft throttle shafts.
• Clockwise and counter-clockwise throttle installations.

Warnings

• Designed for use with 8mm D-shaft throttle shafts. Wiring instructions are included with the sensor.

Highlights

• The Link Throttle Position Sensor has the following specifications:
• Supports clockwise and counter-clockwise operation.
• Non-contact Hall Effect sensing technology.
• 8mm D-shaft input.
• Dual redundant outputs.
• 32mm mounting bolt pattern.
• 5V supply voltage.
• IP68 environmental protection.
• Operating temperature: -40degC to +125degC.
• High-strength, temperature-resistant housing.
• Over 50 million operating cycles.
• 6-wire flying lead.

Product Dimensions

• 540mm(L)x45mm(W)x20mm(H)
• 21.26in(L)x1.77in(W)x0.79in(H)

Product Weight

• 25 grams (0.88 ounces)

Electrical

• Operating Voltage Range: -0.5-5V
• Maximum Input Voltage: 5V
• Gauges of wire: 24AWG/0.2mm2

What's in the Box

• Throttle Position Sensor CW/CCW
• Printed Accessory instructions

Installation and ordering

Confirm connector type, wiring, supply voltage and compatibility with the ECU or connected device before purchase. Follow the relevant Link wiring diagram, calibration and mounting instructions. CAN devices require a compatible CAN configuration and correct bus termination. Accessories are included only where they are explicitly listed below.

Installation and Compatibility Checks

Confirm the specified device compatibility, connectors and installation requirements before ordering. Use a qualified installer for vehicle electrical work.
