Available from JDM Mods NQ, the Link AIM GPS09 Module for AIM Dashes is an engine-data display for a compatible vehicle electronics installation. Use the fitment, technical and package details below to select the correct part for your build.

Manufacturer part number: 100-0170

Models Supported

• 5” MXS, 7” MXG and 10” MXT Strada displays.

Highlights

• GPS frequency: 25 Hz.
• Average positional tolerance: <0.5 m.
• Satellite systems: GPS, GLONASS, BeiDou and Galileo.
• Track database: 4,000+ tracks worldwide.
• Connection: AiM CAN.
• Compatible with MXS, MXG and MXT Strada displays.
• Software: AiM Race Studio 3.

Product Dimensions

• 64.8mm(L)x53.2mm(W)x19.7mm(H)
• 2.55in(L)x2.09in(W)x0.78in(H)

Product Weight

• 60.5 grams (2.13 ounces)

Cable Length

• 1.3m

What's in the Box

• AiM GPS09 Module.
• Integrated CAN Connection Cable.

Installation and ordering

Confirm connector type, wiring, supply voltage and compatibility with the ECU or connected device before purchase. Follow the relevant Link wiring diagram, calibration and mounting instructions. CAN devices require a compatible CAN configuration and correct bus termination. Accessories are included only where they are explicitly listed below.

Installation and Compatibility Checks

Confirm the specified device compatibility, connectors and installation requirements before ordering. Use a qualified installer for vehicle electrical work.
