GReddy Alloy Racing Radiator for Toyota Mark II series JZX100/110

GReddy Aluminum Radiator TW-R FITS Toyota Chaser JZX100 JZX110 1JZ-GTE

The aluminum construction is super light and allows for increased rigidity while also being highly resistant to corrosion. With extensive experience in cooling the 2-row design with wide-tube 36mm core is able to hold the same volume LLC as other more expensive 3-row layouts while also being just as efficient in cooling ability. With quality materials, great design and know-how this setup provides great cooling and cost performance.

Brand: Trust GReddy
Product: Aluminum Radiator TW-R
Part Num: 12013801

SPECIFICATIONS:
Core Type: 2-Row
Core Thickness (mm): 50
Material: Aluminum (with Buffing processing)

COMPATIBILITY NOTES:
– Compatible with OEM Fan Shroud
– Incompatible with Automatic Transmission models
– OEM radiator bracket is required for installation

FEATURES:
50mm Core width:
– Trust Adopted 50mm core for ensure adequate cooling with the correct volume of water.
– Also incorporated an extra fitting for a 1/8pt sensor.
Aluminum Core with Buffing processing:
– Aluminum material and buffing processing were applied for improve resistance to corrosion

Compatible:

Vehicle model: JZX100/JZX110

Engine type: 1JZ-GTE

Year: JZX100 96.09~00.10/JZX110 00.10 ~ 04.11

Note: AT vehicles not allowed

Remarks:

*Shroud needs modification (JZX110)

*Requires GReddy Air Inx Kit TY-M045 JZX100 (12510645)

* Not compatible with vehicles with genuine air cleaners

* Cannot be installed together with the radiator pipe.

Barcode: 4991995219637

Some radiators may need to be ordered from Japan. Please email to confirm availability before purchasing.

PLEASE NOTE: The photos used are for reference purposes only. Product may vary.
