The Turbosmart FPR10 Series provides market-leading fuel control and response via true 1:1 ratio and superior flow and bypass capacity for vehicles with -10 / 10AN fuel systems.
Utilising our Stainless Steel Valve Seat & Milspec Diaphragm the FPR10 Series is suitable for all Fuel types including Race Fuel and aggressive leaded fuels.
Our FPR10 Range includes 10AN inlet and outlet and return fittings and is available in Standard (35psi to 80psi) as well as LP (3psi to 20psi) for Low Pressure and Carburettor Systems to suit 3000HP systems.
Features:
- Stainless Steel Valve Seat
- Suitable for all fuel types
- 1:1 Class Leading Ratio & Response
- Adjustable Pressure
- 1/8 NPT Pressure Sensor Port
- Unique Locking Collar Design
- Milspec Diaphragm
- Detailed Specific Fuel Flow Data & Spec
FPR10 Series available in:
- FPR10 Fuel Pressure Regulator Suit -10AN (Sleeper) TS-0404-1045
- Limited Edition FPR10 Fuel Pressure Regulator Suit -10AN (Platinum) TS-0404-1046
- FPR10 Fuel Pressure Regulator Suit -10AN (Blue) TS-0404-1041
- FPR10 Fuel Pressure Regulator Suit -10AN (Black) TS-0404-1042
- FPR10 Fuel Pressure Regulator Suit -10AN (Purple) TS-0404-1043
- FPR10 Fuel Pressure Regulator Suit -10AN (Red) TS-0404-1044
- FPR10 Low Pressure (LP) Fuel Pressure Regulator Suit -10AN (Black) TS-0404-1142
Supplied With:
- Fuel Pressure Regulator
- Mounting bracket
- 2 x M5 Mounting Screws
- Turbosmart Decal
